What temperatures can the Cascade Ultra-Low Temperature Chiller maintain?

The operating range is -80 °C to -40 °C, with non-standard customization available.

Cascade Ultra-Low Temperature Chiller — 22 – 270 kW

Name: Cascade Ultra-Low Temperature Chiller
Brand: Fuliang Refrigeration

Cascade Ultra-Low Temperature Chiller — Fuliang Refrigeration

Key Specifications

Capacity	22 – 270 kW per unit
Temperature range	-80 °C to -40 °C
Refrigeration principle	Two-stage cascade cycle (high-temp + low-temp stage)
Extended range	Three-stage cascade down to -120 °C available
Control system	In-house developed, coordinated cascade control
Key components	First-tier brand compressors & refrigeration parts

Get Pricing for This Model

Product Overview

About the Cascade Ultra-Low Temperature Chiller

The cascade ultra-low temperature chiller consists of two independent refrigeration cycles — a high-temperature stage and a low-temperature stage — achieving ultra-low temperatures below -60 °C that two-stage compression systems cannot reach.

This cascade unit was developed independently by Fuliang's own technical team; three-stage cascade units down to -120 °C are already in production. The control system, programmed in-house, coordinates every component intelligently, so the unit is as easy to operate as an ordinary chiller. First-tier brand compressors and refrigeration parts with high-efficiency heat exchangers keep the system running stably year after year.

As a manufacturer founded in 2011, Fuliang integrates R&D, design, production and sales of industrial refrigeration equipment. Every unit is built with certified, first-tier components and can be engineered to your exact operating conditions — send us your requirements through the inquiry form for a tailored proposal.

Key Features

Engineering Highlights

Independent high-temperature and low-temperature stages form the cascade cycle, reaching ultra-low temperatures below -60 °C beyond the capability of two-stage compression.
Independently developed by the Fuliang technical team — three-stage cascade units down to -120 °C already available.
In-house programmed control system coordinates all components; operation is as simple as a standard chiller.
International first-tier brand compressors and refrigeration parts with high-efficiency heat exchangers for long-term stability.

Typical Applications

Where This Unit Excels

Ultra-low temperature storage (-80 °C) Pharmaceutical & vaccine cold chain Aerospace & materials testing Scientific research laboratories Special chemical processes

FAQ

Frequently Asked Questions

What capacity range does the Cascade Ultra-Low Temperature Chiller cover?

This series offers 22 – 270 kw per unit. For larger duties, multiple units can be combined — our engineers will size the configuration for your load profile.

What temperatures can it maintain?

The operating range is -80 °C to -40 °C. If your process requires different conditions, non-standard customization is one of our core strengths.

Can the unit be customized for my site?

Yes. As the manufacturer, Fuliang provides non-standard designs for special temperatures, corrosive water, limited space and other constraints. Send your requirements via the inquiry form and you will receive a tailored proposal within 24 hours.
